MD Cowan Super Single Drilling Rigs

MD Cowan Super Single Drilling Rig

a huge asset in the drilling industry

Get your MD Cowan Super Single drilling rigs from Rig Source Inc today.

MD Cowan Super Single drilling rigs have become a huge asset in the drilling industry with its massive 71′-6″ mast. The MD Cowan Super Single drilling rig’s mast is raised and lowered by two hydraulic cylinders. This MD Cowan is completed with a front face integrated top drive rail system.

Top Drive

The trailer MD Cowan Super Single has a Rig Tech RT-400B, 750hp mechaincal drawworks with Easton disc brake with 400K capacity. The hoisting system on the MD Cowan is mounted on an integrated trailer unit with a self contained rig hydraulic power system and drill line spool. The maximum capacity of the MD Cowan is rated at 476,336 lbs with 10 lines, with a maximum single line pull of 70,715 lbs. The maximum speed of the MD Cowan Super Single drilling rig is rated at 140rpm.

Mud Pumps

The MD Cowan Super Single drilling rig is equipped with 2 Gardner Denver PZ-9 triplex mud pums rated at 1000hp each. Offering a mechanical drive with torque converters with each pump driven by Cat 3508 engines rated at 900hp.

Pipe Handling

The MD Cowan Super Single drilling rig has a Power Wrench HT-75 hydraulic torque wrench from U.S. Tools with a maximum make-up torgue of 75,000ft-lbs. As well as 100,000ft-lbs maximum break-out torque.

For current drill rigs for sale or for rent or for specific requests, give us a call today at 630.365.1649.
